| General | |
|---|---|
| Sizes | 10" |
| Colour | Round White or Round Black or Square White or Square Black |
| Physical dimensions (Diameter) | 11.18 mm (284") |
| Physical dimensions (Depth) | 139.5 mm (5.49") |
| Weight | 10" Round: 3 kg (6.61 lbs) 10" Square White: 2.95 kg (6.5 lbs) 10" Square Black: 3.1 kg (6.83 lbs) |
| Water and dust rating | IP65 |
| Speaker type | Subwoofer |
| Continuous power handling (RMS) | 120 W |
| Sensitivity (SPL @ 1 W/1 m) | 87 dB |
| Frequency response (+/- 3 dB) | 30 Hz-2 kHz |
| Nominal impedance | 4 Ω |
| Operating temperature range | 0° to 50° C (32° to 122° F) |
| Cone material | Polypropylene cone with rubber surround |
| Warranty | 3 years |
| Electrical features | |
|---|---|
| Compass safe distance | 381 cm (150") |
| Connections | |
|---|---|
| Speaker connections | Spade Connectors |
| Mounting Dimensions | |
|---|---|
| Mounting diameter clearance | 269 mm (10.59") |
| Mounting depth clearance | 140 mm (5.51") |
| Frontal grille protrusion | 3 mm (0.12") |
